What separates the BESSEY® trigger clamp from the rest is that it has been engineered from the start to offer a clean design, comfortable handles, up to 600 lbs. of potential clamping force and the ability to quickly transform from clamping to spreading. The transition from clamping to spreading requires no tools. All that is required is a quick push of the locking mechanism to disengage the fixed jaw, move it to the opposite end of the rail and re-engage.
-
Powerful Technology, Robust Construction
One-handed clamping or spreading of work pieces with up to 600 lbs. of force.
-
No Tools Required
No tools required to easily convert from clamping to spreading; push button jaw release.
-
Soft Touch Pads
Soft-touch jaw pads eliminate marring of work, and they're removable too. Steel bar for the strength you expect from BESSEY.
-
Ergonomic Composite Handle
Ergonomically shaped composite handle with trigger makes it easy to achieve maximum clamping force.
| Clamping Capacity | Throat Depth | Spreading Capacity | Clamping Force | Approx. Weight | |
| EHKXL12 | 12" | 3 5/8" | 7 1/2 - 19 1/4" | 600 lbs | 2.74 lbs |
| EHKXL24 | 24" | 3 5/8" | 7 1/2 - 31 1/8" | 600 lbs | 3.46 lbs |
